| BootROM - 2.03
Starting CP-0 IOROM 1.07
Booting from SPI NOR flash 1 (0x32)
Found valid image at boot postion 0x000
lmv_ddr: mv_ddr-devel-18.12.0-g2e20f5d (Dec 30 2021 - 16:08:48)
mv_ddr: scrubbing memory...
mv_ddr: completed successfully
BL2: Initiating SCP_BL2 transfer to SCP
U-Boot 2018.03-devel-18.12.3-ga49bd540df (Dec 30 2021 - 16:06:18 +0800)
Model: Marvell Armada 7040 Mochabin development board
SoC: Armada7040-B0; AP806-B0; CP115-A0
Clock: CPU 1400 [MHz]
DDR 800 [MHz]
FABRIC 800 [MHz]
MSS 200 [MHz]
LLC Enabled (Exclusive Mode)
DRAM: 8 GiB
Bus spi@700680 CS0 configured for direct access 00000000f9000000:0x1000000
SF: Detected w25q32bv with page size 256 Bytes, erase size 4 KiB, total 4 MiB
EEPROM configuration pattern not detected.
Comphy chip #0:
Comphy-0: SGMII1 3.125 Gbps
Comphy-1: USB3_HOST0
Comphy-2: SATA0
Comphy-3: SATA1
Comphy-4: SFI0 10.3125 Gbps
Comphy-5: PEX2
UTMI PHY 0 initialized to USB Host0
UTMI PHY 1 initialized to USB Host1
SATA link 0 timeout.
Target spinup took 0 ms.
AHCI 0001.0000 32 slots 2 ports 6 Gbps 0x3 impl SATA mode
flags: 64bit ncq led only pmp fbss pio slum part sxs
PCIE-0: Link down
MMC: sdhci@6e0000: 0
Loading Environment from SPI Flash... OK
Model: Marvell Armada 7040 Mochabin development board
Net: eth0: mvpp2-0 [PRIME], eth1: mvpp2-1, eth2: mvpp2-2
Hit any key to stop autoboot: 0
576 bytes read in 9 ms (62.5 KiB/s)
## Executing script at 06000000
switch to partitions #0, OK
mmc0(part 0) is current device
24275 bytes read in 12 ms (1.9 MiB/s)
11859976 bytes read in 871 ms (13 MiB/s)
## Flattened Device Tree blob at 06f00000
Booting using the fdt blob at 0x6f00000
Using Device Tree in place at 0000000006f00000, end 0000000006f08ed2
Starting kernel ...
[ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd081]
[ 0.000000] Linux version 5.10.104 (builder@buildhost) (aarch64-openwrt-linux-musl-gcc (OpenWrt GCC 11.2.0 r19124-832b90216f) 11.2.0, GNU ld (GNU Binutils) 2.37) #0 SMP Tue Mar 15 23:48:24 2022
[ 0.000000] Machine model: Globalscale MOCHAbin
[ 0.000000] Zone ranges:
[ 0.000000] DMA [mem 0x0000000000000000-0x00000000ffffffff]
[ 0.000000] DMA32 empty
[ 0.000000] Normal [mem 0x0000000100000000-0x000000023fffffff]
[ 0.000000] Movable zone start for each node
[ 0.000000] Early memory node ranges
[ 0.000000] node 0: [mem 0x0000000000000000-0x0000000003ffffff]
[ 0.000000] node 0: [mem 0x0000000004000000-0x00000000041fffff]
[ 0.000000] node 0: [mem 0x0000000004200000-0x00000000bfffffff]
[ 0.000000] node 0: [mem 0x0000000100000000-0x000000023fffffff]
[ 0.000000] Initmem setup node 0 [mem 0x0000000000000000-0x000000023fffffff]
[ 0.000000] psci: probing for conduit method from DT.
[ 0.000000] psci: PSCIv1.1 detected in firmware.
[ 0.000000] psci: Using standard PSCI v0.2 function IDs
[ 0.000000] psci: MIGRATE_INFO_TYPE not supported.
[ 0.000000] psci: SMC Calling Convention v1.1
[ 0.000000] percpu: Embedded 16 pages/cpu s27672 r8192 d29672 u65536
[ 0.000000] Detected PIPT I-cache on CPU0
[ 0.000000] CPU features: detected: Spectre-v2
[ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 2064384
[ 0.000000] Kernel command line: root=PARTUUID=56839e07-02 rw rootwait console=ttyS0,115200
[ 0.000000] Dentry cache hash table entries: 1048576 (order: 11, 8388608 bytes, linear)
[ 0.000000] Inode-cache hash table entries: 524288 (order: 10, 4194304 bytes, linear)
[ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off
[ 0.000000] software IO TLB: mapped [mem 0x00000000bc000000-0x00000000c0000000] (64MB)
[ 0.000000] Memory: 8164940K/8388608K available (8062K kernel code, 894K rwdata, 2092K rodata, 448K init, 284K bss, 223668K reserved, 0K cma-reserved)
[ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1
[ 0.000000] rcu: Hierarchical RCU implementation.
[ 0.000000] Tracing variant of Tasks RCU enabled.
[ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies.
[ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
[ 0.000000] GIC: Adjusting CPU interface base to 0x00000000f022f000
[ 0.000000] GIC: Using split EOI/Deactivate mode
[ 0.000000] GICv2m: DT overriding V2M MSI_TYPER (base:160, num:32)
[ 0.000000] GICv2m: range[mem 0xf0280000-0xf0280fff], SPI[160:191]
[ 0.000000] GICv2m: DT overriding V2M MSI_TYPER (base:192, num:32)
[ 0.000000] GICv2m: range[mem 0xf0290000-0xf0290fff], SPI[192:223]
[ 0.000000] GICv2m: DT overriding V2M MSI_TYPER (base:224, num:32)
[ 0.000000] GICv2m: range[mem 0xf02a0000-0xf02a0fff], SPI[224:255]
[ 0.000000] GICv2m: DT overriding V2M MSI_TYPER (base:256, num:32)
[ 0.000000] GICv2m: range[mem 0xf02b0000-0xf02b0fff], SPI[256:287]
[ 0.000000] random: get_random_bytes called from start_kernel+0x3a0/0x4e4 with crng_init=0
[ 0.000000] arch_timer: cp15 timer(s) running at 25.00MHz (phys).
[ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x5c40939b5, max_idle_ns: 440795202646 ns
[ 0.000002] sched_clock: 56 bits at 25MHz, resolution 40ns, wraps every 4398046511100ns
[ 0.000083] Calibrating delay loop (skipped), value calculated using timer frequency.. 50.00 BogoMIPS (lpj=250000)
[ 0.000091] pid_max: default: 32768 minimum: 301
[ 0.000208] Mount-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.000265] Mountpoint-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.000954] rcu: Hierarchical SRCU implementation.
[ 0.001018] dyndbg: Ignore empty _ddebug table in a CONFIG_DYNAMIC_DEBUG_CORE build
[ 0.001196] smp: Bringing up secondary CPUs ...
[ 0.001522] Detected PIPT I-cache on CPU1
[ 0.001559] CPU1: Booted secondary processor 0x0000000001 [0x410fd081]
[ 0.001912] Detected PIPT I-cache on CPU2
[ 0.001942] CPU2: Booted secondary processor 0x0000000100 [0x410fd081]
[ 0.002296] Detected PIPT I-cache on CPU3
[ 0.002317] CPU3: Booted secondary processor 0x0000000101 [0x410fd081]
[ 0.002357] smp: Brought up 1 node, 4 CPUs
[ 0.002369] SMP: Total of 4 processors activated.
[ 0.002374] CPU features: detected: 32-bit EL0 Support
[ 0.002378] CPU features: detected: CRC32 instructions
[ 0.002414] CPU features: emulated: Privileged Access Never (PAN) using TTBR0_EL1 switching
[ 0.002419] CPU: All CPU(s) started at EL2
[ 0.002434] alternatives: patching kernel code
[ 0.004821] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns
[ 0.004832] futex hash table entries: 1024 (order: 4, 65536 bytes, linear)
[ 0.004901] pinctrl core: initialized pinctrl subsystem
[ 0.005531] NET: Registered protocol family 16
[ 0.005948] DMA: preallocated 1024 KiB GFP_KERNEL pool for atomic allocations
[ 0.006154] DMA: preallocated 1024 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations
[ 0.006357] DMA: preallocated 1024 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations
[ 0.006566] thermal_sys: Registered thermal governor 'step_wise'
[ 0.006999] cpuidle: using governor ladder
[ 0.007047] ASID allocator initialised with 65536 entries
[ 0.019486] cryptd: max_cpu_qlen set to 1000
[ 0.020585] SCSI subsystem initialized
[ 0.020790] usbcore: registered new interface driver usbfs
[ 0.020812] usbcore: registered new interface driver hub
[ 0.020832] usbcore: registered new device driver usb
[ 0.021389] clocksource: Switched to clocksource arch_sys_counter
[ 0.021702] NET: Registered protocol family 2
[ 0.022168] IP idents hash table entries: 131072 (order: 8, 1048576 bytes, linear)
[ 0.024467] tcp_listen_portaddr_hash hash table entries: 4096 (order: 4, 65536 bytes, linear)
[ 0.024532] TCP established hash table entries: 65536 (order: 7, 524288 bytes, linear)
[ 0.024828] TCP bind hash table entries: 65536 (order: 8, 1048576 bytes, linear)
[ 0.025441] TCP: Hash tables configured (established 65536 bind 65536)
[ 0.025537] UDP hash table entries: 4096 (order: 5, 131072 bytes, linear)
[ 0.025651] UDP-Lite hash table entries: 4096 (order: 5, 131072 bytes, linear)
[ 0.025852] NET: Registered protocol family 1
[ 0.025870] PCI: CLS 0 bytes, default 64
[ 0.026495] workingset: timestamp_bits=46 max_order=21 bucket_order=0
[ 0.028232] squashfs: version 4.0 (2009/01/31) Phillip Lougher
[ 0.028238] jffs2: version 2.2 (NAND) (SUMMARY) (LZMA) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc.
[ 0.028695] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 250)
[ 0.030160] armada-ap806-pinctrl f06f4000.system-controller:pinctrl: registered pinctrl driver
[ 0.030555] armada-cp110-pinctrl f2440000.system-controller:pinctrl: registered pinctrl driver
[ 0.032976] mv_xor_v2 f0400000.xor: Marvell Version 2 XOR driver
[ 0.033433] mv_xor_v2 f0420000.xor: Marvell Version 2 XOR driver
[ 0.033889] mv_xor_v2 f0440000.xor: Marvell Version 2 XOR driver
[ 0.034370] mv_xor_v2 f0460000.xor: Marvell Version 2 XOR driver
[ 0.034876] mv_xor_v2 f26a0000.xor: Marvell Version 2 XOR driver
[ 0.035350] mv_xor_v2 f26c0000.xor: Marvell Version 2 XOR driver
[ 0.035486] Serial: 8250/16550 driver, 16 ports, IRQ sharing enabled
[ 0.036602] printk: console [ttyS0] disabled
[ 0.036651] f0512000.serial: ttyS0 at MMIO 0xf0512000 (irq = 16, base_baud = 12500000) is a 16550A
[ 0.722327] printk: console [ttyS0] enabled
[ 0.727056] f2702000.serial: ttyS1 at MMIO 0xf2702000 (irq = 33, base_baud = 15625000) is a 16550A
[ 0.736461] omap_rng f2760000.trng: Random Number Generator ver. 203b34c
[ 0.736774] random: fast init done
[ 0.746639] random: crng init done
[ 0.751638] loop: module loaded
[ 0.754812] Loading iSCSI transport class v2.0-870.
[ 0.760547] ahci f2540000.sata: supply ahci not found, using dummy regulator
[ 0.767713] ahci f2540000.sata: supply phy not found, using dummy regulator
[ 0.774927] platform f2540000.sata:sata-port@0: supply target not found, using dummy regulator
[ 0.784873] spi-nor spi2.0: w25q32 (4096 Kbytes)
[ 0.789608] 3 fixed-partitions partitions found on MTD device spi2.0
[ 0.795999] Creating 3 MTD partitions on "spi2.0":
[ 0.800810] 0x000000000000-0x0000003e0000 : "u-boot"
[ 0.806007] 0x0000003e0000-0x0000003f0000 : "hw-info"
[ 0.811219] 0x0000003f0000-0x000000400000 : "u-boot-env"
[ 0.818669] hwmon hwmon0: temp1_input not attached to any thermal zone
[ 0.827799] mv88e6085 f212a200.mdio-mii:03: switch 0x3400 detected: Marvell 88E6141, revision 0
[ 0.890127] hwmon hwmon1: temp1_input not attached to any thermal zone
[ 0.902128] hwmon hwmon2: temp1_input not attached to any thermal zone
[ 0.913921] hwmon hwmon3: temp1_input not attached to any thermal zone
[ 0.925714] hwmon hwmon4: temp1_input not attached to any thermal zone
[ 0.941291] mvpp2 f2000000.ethernet: using 8 per-cpu buffers
[ 0.955489] ehci_hcd: USB 2.0 'Enhanced' Host Controller (EHCI) Driver
[ 0.962053] ehci-pci: EHCI PCI platform driver
[ 0.966542] ehci-platform: EHCI generic platform driver
[ 0.971892] ehci-orion: EHCI orion driver
[ 0.976236] xhci-hcd f2510000.usb3: xHCI Host Controller
[ 0.981589] xhci-hcd f2510000.usb3: new USB bus registered, assigned bus number 1
[ 0.989163] xhci-hcd f2510000.usb3: hcc params 0x0a000990 hci version 0x100 quirks 0x0000000000010010
[ 0.998451] xhci-hcd f2510000.usb3: irq 37, io mem 0xf2510000
[ 1.004511] hub 1-0:1.0: USB hub found
[ 1.008288] hub 1-0:1.0: 1 port detected
[ 1.012331] xhci-hcd f2510000.usb3: xHCI Host Controller
[ 1.017669] xhci-hcd f2510000.usb3: new USB bus registered, assigned bus number 2
[ 1.025195] xhci-hcd f2510000.usb3: Host supports USB 3.0 SuperSpeed
[ 1.031606] usb usb2: We don't know the algorithms for LPM for this host, disabling LPM.
[ 1.039869] hub 2-0:1.0: USB hub found
[ 1.043671] hub 2-0:1.0: 1 port detected
[ 1.047841] usbcore: registered new interface driver usb-storage
[ 1.054100] armada38x-rtc f2284000.rtc: registered as rtc0
[ 1.059624] armada38x-rtc f2284000.rtc: setting system clock to 2022-03-17T12:49:12 UTC (1647521352)
[ 1.068850] i2c /dev entries driver
[ 1.072854] pca953x 0-0039: supply vcc not found, using dummy regulator
[ 1.079548] pca953x 0-0039: using no AI
[ 1.099327] sdhci: Secure Digital Host Controller Interface driver
[ 1.105573] sdhci: Copyright(c) Pierre Ossman
[ 1.110159] sdhci-pltfm: SDHCI platform and OF driver helper
[ 1.123162] NET: Registered protocol family 10
[ 1.128038] Segment Routing with IPv6
[ 1.131762] NET: Registered protocol family 17
[ 1.136246] bridge: filtering via arp/ip/ip6tables is no longer available by default. Update your scripts to load br_netfilter if you need this.
[ 1.141532] mmc0: SDHCI controller on f06e0000.sdhci [f06e0000.sdhci] using ADMA 64-bit
[ 1.157611] 8021q: 802.1Q VLAN Support v1.8
[ 1.164512] armada8k-pcie f2640000.pcie: host bridge /cp0/pcie@f2640000 ranges:
[ 1.171915] armada8k-pcie f2640000.pcie: MEM 0x00f8000000..0x00f8efffff -> 0x00f8000000
[ 1.227429] mmc0: new high speed MMC card at address 0001
[ 1.233711] mmcblk0: mmc0:0001 DF4016 14.7 GiB
[ 1.238698] mmcblk0boot0: mmc0:0001 DF4016 partition 1 4.00 MiB
[ 1.244917] mmcblk0boot1: mmc0:0001 DF4016 partition 2 4.00 MiB
[ 1.250924] mmcblk0rpmb: mmc0:0001 DF4016 partition 3 4.00 MiB, chardev (248:0)
[ 1.259425] mmcblk0: p1 p2
[ 2.171413] armada8k-pcie f2640000.pcie: Phy link never came up
[ 2.177381] armada8k-pcie f2640000.pcie: Link not up after reconfiguration
[ 2.184486] armada8k-pcie f2640000.pcie: PCI host bridge to bus 0000:00
[ 2.191147] pci_bus 0000:00: root bus resource [bus 00-ff]
[ 2.196689] pci_bus 0000:00: root bus resource [mem 0xf8000000-0xf8efffff]
[ 2.203665] pci 0000:00:00.0: [11ab:0110] type 01 class 0x060400
[ 2.209730] pci 0000:00:00.0: reg 0x10: [mem 0x00000000-0x000fffff]
[ 2.216146] pci 0000:00:00.0: supports D1 D2
[ 2.220449] pci 0000:00:00.0: PME# supported from D0 D1 D3hot
[ 2.231837] pci 0000:00:00.0: BAR 0: assigned [mem 0xf8000000-0xf80fffff]
[ 2.238676] pci 0000:00:00.0: PCI bridge to [bus 01-ff]
[ 2.807920] pcieport 0000:00:00.0: AER: enabled with IRQ 43
[ 2.814119] ahci f2540000.sata: supply ahci not found, using dummy regulator
[ 2.821331] ahci f2540000.sata: supply phy not found, using dummy regulator
[ 2.828469] platform f2540000.sata:sata-port@0: supply target not found, using dummy regulator
[ 2.837716] platform f2540000.sata:sata-port@1: supply target not found, using dummy regulator
[ 2.848802] ahci f2540000.sata: masking port_map 0x3 -> 0x3
[ 2.854497] ahci f2540000.sata: AHCI 0001.0000 32 slots 2 ports 6 Gbps 0x3 impl platform mode
[ 2.863082] ahci f2540000.sata: flags: 64bit ncq sntf led only pmp fbs pio slum part sxs
[ 2.872124] scsi host0: ahci
[ 2.875304] scsi host1: ahci
[ 2.878305] ata1: SATA max UDMA/133 mmio [mem 0xf2540000-0xf256ffff] port 0x100 irq 44
[ 2.886272] ata2: SATA max UDMA/133 mmio [mem 0xf2540000-0xf256ffff] port 0x180 irq 44
[ 2.895496] sfp sfp-eth0: Host maximum power 1.0W
[ 2.903358] sfp sfp-eth2: Host maximum power 1.0W
[ 2.911642] mv88e6085 f212a200.mdio-mii:03: switch 0x3400 detected: Marvell 88E6141, revision 0
[ 2.971470] hwmon hwmon1: temp1_input not attached to any thermal zone
[ 2.982872] hwmon hwmon2: temp1_input not attached to any thermal zone
[ 2.993976] hwmon hwmon3: temp1_input not attached to any thermal zone
[ 3.005581] hwmon hwmon4: temp1_input not attached to any thermal zone
[ 3.022294] mvpp2 f2000000.ethernet: using 8 per-cpu buffers
[ 3.057359] mvpp2 f2000000.ethernet eth0: Using firmware node mac address 00:51:82:11:22:00
[ 3.069316] mvpp2 f2000000.ethernet eth1: Using firmware node mac address 00:51:82:11:22:01
[ 3.079945] mvpp2 f2000000.ethernet eth2: Using firmware node mac address 00:51:82:11:22:02
[ 3.109402] xhci-hcd f2500000.usb3: xHCI Host Controller
[ 3.114766] xhci-hcd f2500000.usb3: new USB bus registered, assigned bus number 3
[ 3.122374] xhci-hcd f2500000.usb3: hcc params 0x0a000990 hci version 0x100 quirks 0x0000000000010010
[ 3.131688] xhci-hcd f2500000.usb3: irq 36, io mem 0xf2500000
[ 3.138060] hub 3-0:1.0: USB hub found
[ 3.141891] hub 3-0:1.0: 1 port detected
[ 3.146039] xhci-hcd f2500000.usb3: xHCI Host Controller
[ 3.151402] xhci-hcd f2500000.usb3: new USB bus registered, assigned bus number 4
[ 3.158922] xhci-hcd f2500000.usb3: Host supports USB 3.0 SuperSpeed
[ 3.165335] usb usb4: We don't know the algorithms for LPM for this host, disabling LPM.
[ 3.173646] hub 4-0:1.0: USB hub found
[ 3.177422] hub 4-0:1.0: 1 port detected
[ 3.184215] mv88e6085 f212a200.mdio-mii:03: switch 0x3400 detected: Marvell 88E6141, revision 0
[ 3.241427] hwmon hwmon1: temp1_input not attached to any thermal zone
[ 3.242574] ata1: SATA link down (SStatus 0 SControl 300)
[ 3.254223] hwmon hwmon2: temp1_input not attached to any thermal zone
[ 3.265043] hwmon hwmon3: temp1_input not attached to any thermal zone
[ 3.275775] hwmon hwmon4: temp1_input not attached to any thermal zone
[ 3.431426] usb 3-1: new high-speed USB device number 2 using xhci-hcd
[ 3.431447] ata2: SATA link up 6.0 Gbps (SStatus 133 SControl 300)
[ 3.432124] ata2.00: ATA-11: WDC WDS100T1R0B-68A4Z0, 411000WR, max UDMA/133
[ 3.451359] ata2.00: 1953525168 sectors, multi 1: LBA48 NCQ (depth 32)
[ 3.459999] ata2.00: configured for UDMA/133
[ 3.464549] scsi 1:0:0:0: Direct-Access ATA WDC WDS100T1R0B 00WR PQ: 0 ANSI: 5
[ 3.473271] sd 1:0:0:0: [sda] 1953525168 512-byte logical blocks: (1.00 TB/932 GiB)
[ 3.480997] sd 1:0:0:0: [sda] Write Protect is off
[ 3.485886] sd 1:0:0:0: [sda] Write cache: enabled, read cache: enabled, doesn't support DPO or FUA
[ 3.495609] sd 1:0:0:0: [sda] Attached SCSI removable disk
[ 3.632815] hub 3-1:1.0: USB hub found
[ 3.636665] hub 3-1:1.0: 4 ports detected
[ 3.791465] usb 4-1: new SuperSpeed Gen 1 USB device number 2 using xhci-hcd
[ 3.822536] hub 4-1:1.0: USB hub found
[ 3.826398] hub 4-1:1.0: 4 ports detected
[ 4.003462] mvpp2 f2000000.ethernet: all ports have a low MTU, switching to per-cpu buffers
[ 4.045883] mvpp2 f2000000.ethernet: using 8 per-cpu buffers
[ 4.060988] mv88e6085 f212a200.mdio-mii:03 lan0 (uninitialized): PHY [!cp0!config-space@f2000000!mdio@12a200!switch@3!mdio:11] driver [Marvell 88E6341 Family] (irq=77)
[ 4.083652] mv88e6085 f212a200.mdio-mii:03 lan1 (uninitialized): PHY [!cp0!config-space@f2000000!mdio@12a200!switch@3!mdio:12] driver [Marvell 88E6341 Family] (irq=78)
[ 4.106233] mv88e6085 f212a200.mdio-mii:03 lan2 (uninitialized): PHY [!cp0!config-space@f2000000!mdio@12a200!switch@3!mdio:13] driver [Marvell 88E6341 Family] (irq=79)
[ 4.128216] mv88e6085 f212a200.mdio-mii:03 lan3 (uninitialized): PHY [!cp0!config-space@f2000000!mdio@12a200!switch@3!mdio:14] driver [Marvell 88E6341 Family] (irq=80)
[ 4.156378] mv88e6085 f212a200.mdio-mii:03: configuring for inband/2500base-x link mode
[ 4.164840] usb 4-1.2: new SuperSpeed Gen 1 USB device number 3 using xhci-hcd
[ 4.198154] DSA: tree 0 setup
[ 4.210244] VFS: Mounted root (squashfs filesystem) readonly on device 179:2.
[ 4.217572] Freeing unused kernel memory: 448K
[ 4.223605] usb-storage 4-1.2:1.0: USB Mass Storage device detected
[ 4.230115] scsi host2: usb-storage 4-1.2:1.0
[ 4.281502] Run /sbin/init as init process
[ 4.462296] init: Console is alive
[ 4.575773] kmodloader: loading kernel modules from /etc/modules-boot.d/*
[ 4.614539] kmodloader: done loading kernel modules from /etc/modules-boot.d/*
[ 4.627071] init: - preinit -
[ 5.107929] mvpp2 f2000000.ethernet eth1: configuring for fixed/2500base-x link mode
[ 5.116907] mvpp2 f2000000.ethernet eth1: Link is Up - 2.5Gbps/Full - flow control off
[ 5.121943] mv88e6085 f212a200.mdio-mii:03 lan0: configuring for phy/ link mode
[ 5.133988] 8021q: adding VLAN 0 to HW filter on device lan0
[ 5.139699] IPv6: ADDRCONF(NETDEV_CHANGE): eth1: link becomes ready
Press the [f] key and hit [enter] to enter failsafe mode
Press the [1], [2], [3] or [4] key and hit [enter] to select the debug level
[ 5.282191] scsi 2:0:0:0: Direct-Access Kingston DataTraveler 3.0 PQ: 0 ANSI: 6
[ 5.291592] sd 2:0:0:0: [sdb] 60437492 512-byte logical blocks: (30.9 GB/28.8 GiB)
[ 5.299429] sd 2:0:0:0: [sdb] Write Protect is off
[ 5.304458] sd 2:0:0:0: [sdb] Write cache: disabled, read cache: enabled, doesn't support DPO or FUA
[ 5.315481] sdb: sdb1
[ 5.318889] sd 2:0:0:0: [sdb] Attached SCSI removable disk
[ 8.624024] F2FS-fs (loop0): Mounted with checkpoint version = 3d07f56a
[ 8.631266] mount_root: switching to f2fs overlay
[ 8.636546] overlayfs: "xino" feature enabled using 32 upper inode bits.
[ 8.763522] EXT4-fs (mmcblk0p1): mounted filesystem without journal. Opts: (null)
[ 8.777403] urandom-seed: Seeding with /etc/urandom.seed
[ 8.881604] procd: - early -
[ 9.534268] procd: - ubus -
[ 9.588630] procd: - init -
Please press Enter to activate this console.
[ 9.849260] kmodloader: loading kernel modules from /etc/modules.d/*
[ 9.871685] urngd: v1.0.2 started.
[ 9.904154] PPP generic driver version 2.4.2
[ 9.908866] NET: Registered protocol family 24
[ 9.915460] kmodloader: done loading kernel modules from /etc/modules.d/*
[ 12.772877] mvpp2 f2000000.ethernet eth1: Link is Down
[ 12.791027] mvpp2 f2000000.ethernet eth1: configuring for fixed/2500base-x link mode
[ 12.799236] mvpp2 f2000000.ethernet eth1: Link is Up - 2.5Gbps/Full - flow control off
[ 12.810596] mv88e6085 f212a200.mdio-mii:03 lan0: configuring for phy/ link mode
[ 12.820825] 8021q: adding VLAN 0 to HW filter on device lan0
[ 12.826565] IPv6: ADDRCONF(NETDEV_CHANGE): eth1: link becomes ready
[ 12.943561] br-lan: port 1(lan0) entered blocking state
[ 12.948836] br-lan: port 1(lan0) entered disabled state
[ 12.955956] device lan0 entered promiscuous mode
[ 12.960609] device eth1 entered promiscuous mode
[ 13.070259] mv88e6085 f212a200.mdio-mii:03 lan1: configuring for phy/ link mode
[ 13.078833] 8021q: adding VLAN 0 to HW filter on device lan1
[ 13.194505] br-lan: port 2(lan1) entered blocking state
[ 13.199759] br-lan: port 2(lan1) entered disabled state
[ 13.206736] device lan1 entered promiscuous mode
[ 13.233762] mv88e6085 f212a200.mdio-mii:03 lan2: configuring for phy/ link mode
[ 13.242384] 8021q: adding VLAN 0 to HW filter on device lan2
[ 13.355709] br-lan: port 3(lan2) entered blocking state
[ 13.360979] br-lan: port 3(lan2) entered disabled state
[ 13.368756] device lan2 entered promiscuous mode
[ 13.396173] mv88e6085 f212a200.mdio-mii:03 lan3: configuring for phy/ link mode
[ 13.404780] 8021q: adding VLAN 0 to HW filter on device lan3
[ 13.525721] br-lan: port 4(lan3) entered blocking state
[ 13.530990] br-lan: port 4(lan3) entered disabled state
[ 13.539530] device lan3 entered promiscuous mode
[ 13.580818] mvpp2 f2000000.ethernet eth0: configuring for inband/10gbase-r link mode
[ 13.589847] br-wan: port 1(eth0) entered blocking state
[ 13.595139] br-wan: port 1(eth0) entered disabled state
[ 13.600873] device eth0 entered promiscuous mode
[ 13.607793] br-wan: port 1(eth0) entered blocking state
[ 13.613068] br-wan: port 1(eth0) entered forwarding state
[ 13.624145] mvpp2 f2000000.ethernet eth2: PHY [f212a200.mdio-mii:01] driver [Marvell 88E1510] (irq=POLL)
[ 13.633761] mvpp2 f2000000.ethernet eth2: configuring for phy/rgmii-id link mode
[ 13.642325] br-wan: port 2(eth2) entered blocking state
[ 13.647576] br-wan: port 2(eth2) entered disabled state
[ 13.653310] device eth2 entered promiscuous mode
[ 13.658063] br-wan: port 2(eth2) entered blocking state
[ 13.663322] br-wan: port 2(eth2) entered forwarding state
[ 13.784836] br-wan: port 1(eth0) entered disabled state
[ 13.790846] br-wan: port 2(eth2) entered disabled state
[ 17.831989] mvpp2 f2000000.ethernet eth2: Link is Up - 1Gbps/Full - flow control off
[ 17.839798] br-wan: port 2(eth2) entered blocking state
[ 17.845068] br-wan: port 2(eth2) entered forwarding state
BusyBox v1.35.0 (2022-03-15 23:48:24 UTC) built-in shell (ash)
_______ ________ __
| |.-----.-----.-----.| | | |.----.| |_
| - || _ | -__| || | | || _|| _|
|_______|| __|_____|__|__||________||__| |____|
|__| W I R E L E S S F R E E D O M
-----------------------------------------------------
OpenWrt SNAPSHOT, r19124-832b90216f
-----------------------------------------------------
=== WARNING! =====================================
There is no root password defined on this device!
Use the "passwd" command to set up a new password
in order to prevent unauthorized SSH logins.
--------------------------------------------------
root@OpenWrt:/#
root@OpenWrt:/# uname -ar
Linux OpenWrt 5.10.104 #0 SMP Tue Mar 15 23:48:24 2022 aarch64 GNU/Linux
root@OpenWrt:/# cat /etc/openwrt_release
DISTRIB_ID='OpenWrt'
DISTRIB_RELEASE='SNAPSHOT'
DISTRIB_REVISION='r19124-832b90216f'
DISTRIB_TARGET='mvebu/cortexa72'
DISTRIB_ARCH='aarch64_cortex-a72'
DISTRIB_DESCRIPTION='OpenWrt SNAPSHOT r19124-832b90216f'
DISTRIB_TAINTS=''
root@OpenWrt:/# opkg update && opkg install luci-mod-admin-full luci-ssl
Downloading https://downloads.openwrt.org/snapshots/targets/mvebu/cortexa72/packages/Packages.gz
Updated list of available packages in /var/opkg-lists/openwrt_core
Downloading https://downloads.openwrt.org/snapshots/targets/mvebu/cortexa72/packages/Packages.sig
Signature check passed.
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/Packages.gz
Updated list of available packages in /var/opkg-lists/openwrt_base
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/Packages.sig
Signature check passed.
Downloading https://downloads.openwrt.org/snapshots/targets/mvebu/cortexa72/kmods/5.10.104-1-08c8d2b2068318c202f4b6a78c92f5dc/Packages.gz
Updated list of available packages in /var/opkg-lists/openwrt_kmods
Downloading https://downloads.openwrt.org/snapshots/targets/mvebu/cortexa72/kmods/5.10.104-1-08c8d2b2068318c202f4b6a78c92f5dc/Packages.sig
Signature check passed.
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/Packages.gz
Updated list of available packages in /var/opkg-lists/openwrt_luci
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/Packages.sig
Signature check passed.
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/packages/Packages.gz
Updated list of available packages in /var/opkg-lists/openwrt_packages
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/packages/Packages.sig
Signature check passed.
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/routing/Packages.gz
Updated list of available packages in /var/opkg-lists/openwrt_routing
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/routing/Packages.sig
Signature check passed.
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/telephony/Packages.gz
Updated list of available packages in /var/opkg-lists/openwrt_telephony
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/telephony/Packages.sig
Signature check passed.
Installing luci-mod-admin-full (git-19.253.48496-3f93650) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-mod-admin-full_git-19.253.48496-3f93650_all.ipk
Installing liblua5.1.5 (5.1.5-10) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/liblua5.1.5_5.1.5-10_aarch64_cortex-a72.ipk
Installing lua (5.1.5-10) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/lua_5.1.5-10_aarch64_cortex-a72.ipk
Installing luci-lib-nixio (git-20.234.06894-c4a4e43) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-lib-nixio_git-20.234.06894-c4a4e43_aarch64_cortex-a72.ipk
Installing luci-lib-ip (git-20.250.76529-62505bd) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-lib-ip_git-20.250.76529-62505bd_aarch64_cortex-a72.ipk
Installing rpcd (2022-02-07-909f2a04-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/rpcd_2022-02-07-909f2a04-1_aarch64_cortex-a72.ipk
Installing libubus-lua (2022-02-28-584f56a2-2) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/libubus-lua_2022-02-28-584f56a2-2_aarch64_cortex-a72.ipk
Installing luci-lib-jsonc (git-19.317.29469-8da8f38) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-lib-jsonc_git-19.317.29469-8da8f38_aarch64_cortex-a72.ipk
Installing liblucihttp0 (2022-02-13-cc851838-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/liblucihttp0_2022-02-13-cc851838-1_aarch64_cortex-a72.ipk
Installing liblucihttp-lua (2022-02-13-cc851838-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/liblucihttp-lua_2022-02-13-cc851838-1_aarch64_cortex-a72.ipk
Installing luci-lib-base (git-20.232.39649-1f6dc29) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-lib-base_git-20.232.39649-1f6dc29_all.ipk
Installing rpcd-mod-file (2022-02-07-909f2a04-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/rpcd-mod-file_2022-02-07-909f2a04-1_aarch64_cortex-a72.ipk
Installing rpcd-mod-luci (20210614) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/rpcd-mod-luci_20210614_aarch64_cortex-a72.ipk
Installing cgi-io (2021-09-08-98cef9dd-20) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/packages/cgi-io_2021-09-08-98cef9dd-20_aarch64_cortex-a72.ipk
Installing luci-base (git-22.058.70382-d29400e) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-base_git-22.058.70382-d29400e_aarch64_cortex-a72.ipk
Installing libiwinfo-data (2021-07-11-a0a0e02d-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/libiwinfo-data_2021-07-11-a0a0e02d-1_aarch64_cortex-a72.ipk
Installing libiwinfo20210430 (2021-07-11-a0a0e02d-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/libiwinfo20210430_2021-07-11-a0a0e02d-1_aarch64_cortex-a72.ipk
Installing libiwinfo-lua (2021-07-11-a0a0e02d-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/libiwinfo-lua_2021-07-11-a0a0e02d-1_aarch64_cortex-a72.ipk
Installing luci-mod-status (git-22.041.71554-e6f21f8) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-mod-status_git-22.041.71554-e6f21f8_aarch64_cortex-a72.ipk
Installing luci-mod-system (git-22.019.40203-e0ff3ff) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-mod-system_git-22.019.40203-e0ff3ff_all.ipk
Installing rpcd-mod-iwinfo (2022-02-07-909f2a04-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/rpcd-mod-iwinfo_2022-02-07-909f2a04-1_aarch64_cortex-a72.ipk
Installing luci-mod-network (git-22.049.73249-8890111) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-mod-network_git-22.049.73249-8890111_all.ipk
Installing luci-ssl (git-20.244.36115-e10f954) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-ssl_git-20.244.36115-e10f954_all.ipk
Installing uhttpd (2022-02-07-2f8b1360-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/uhttpd_2022-02-07-2f8b1360-1_aarch64_cortex-a72.ipk
Installing uhttpd-mod-ubus (2022-02-07-2f8b1360-1) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/uhttpd-mod-ubus_2022-02-07-2f8b1360-1_aarch64_cortex-a72.ipk
Installing luci-theme-bootstrap (git-22.055.81918-06b3517) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-theme-bootstrap_git-22.055.81918-06b3517_all.ipk
Installing luci-app-firewall (git-22.046.84457-2178444) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-app-firewall_git-22.046.84457-2178444_all.ipk
Installing luci-app-opkg (git-22.043.53495-1e6f630) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-app-opkg_git-22.043.53495-1e6f630_all.ipk
Installing luci-proto-ppp (git-21.158.38888-88b9d84) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-proto-ppp_git-21.158.38888-88b9d84_all.ipk
Installing luci-proto-ipv6 (git-21.148.48881-79947af) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci-proto-ipv6_git-21.148.48881-79947af_all.ipk
Installing rpcd-mod-rrdns (20170710) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/rpcd-mod-rrdns_20170710_aarch64_cortex-a72.ipk
Installing luci (git-20.074.84698-ead5e81) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/luci/luci_git-20.074.84698-ead5e81_all.ipk
Installing libwolfssl5.1.1.5fb91bea (5.1.1-stable-2) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/libwolfssl5.1.1.5fb91bea_5.1.1-stable-2_aarch64_cortex-a72.ipk
Installing px5g-wolfssl (4) to root...
Downloading https://downloads.openwrt.org/snapshots/packages/aarch64_cortex-a72/base/px5g-wolfssl_4_aarch64_cortex-a72.ipk
Configuring liblucihttp0.
Configuring cgi-io.
Configuring liblua5.1.5.
Configuring lua.
Configuring luci-lib-nixio.
Configuring luci-lib-ip.
Configuring luci-lib-jsonc.
Configuring liblucihttp-lua.
Configuring luci-lib-base.
Configuring rpcd.
Configuring libubus-lua.
Configuring libiwinfo-data.
Configuring libiwinfo20210430.
Configuring libiwinfo-lua.
Configuring rpcd-mod-file.
Configuring rpcd-mod-luci.
Configuring luci-base.
Configuring luci-mod-system.
Configuring luci-mod-status.
Configuring rpcd-mod-iwinfo.
Configuring luci-mod-network.
Configuring luci-mod-admin-full.
Configuring luci-app-opkg.
Configuring luci-theme-bootstrap.
/luci-static/bootstrap
Configuring libwolfssl5.1.1.5fb91bea.
Configuring px5g-wolfssl.
Configuring luci-app-firewall.
Configuring uhttpd.
4+0 records in
4+0 records out
Generating EC private key
Generating selfsigned certificate with subject '/C=ZZ/ST=Somewhere/L=Unknown/O=OpenWrt133b25eb/CN=OpenWrt' and validity 20220317125219-20240316125219
Configuring uhttpd-mod-ubus.
Configuring luci-proto-ppp.
Configuring luci-proto-ipv6.
Configuring rpcd-mod-rrdns.
Configuring luci.
Configuring luci-ssl.
root@OpenWrt:/# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
inet6 ::1/128 scope host
valid_lft forever preferred_lft forever
2: eth0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc mq master br-wan state DOWN qlen 2048
link/ether 00:51:82:11:22:00 brd ff:ff:ff:ff:ff:ff
3: eth1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1508 qdisc mq state UP qlen 2048
link/ether 00:51:82:11:22:01 brd ff:ff:ff:ff:ff:ff
inet6 fe80::251:82ff:fe11:2201/64 scope link
valid_lft forever preferred_lft forever
4: eth2: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq master br-wan state UP qlen 2048
link/ether 00:51:82:11:22:02 brd ff:ff:ff:ff:ff:ff
5: lan0@eth1: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue master br-lan state LOWERLAYERDOWN qlen 1000
link/ether 00:51:82:11:22:01 brd ff:ff:ff:ff:ff:ff
6: lan1@eth1: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue master br-lan state LOWERLAYERDOWN qlen 1000
link/ether 00:51:82:11:22:01 brd ff:ff:ff:ff:ff:ff
7: lan2@eth1: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue master br-lan state LOWERLAYERDOWN qlen 1000
link/ether 00:51:82:11:22:01 brd ff:ff:ff:ff:ff:ff
8: lan3@eth1: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue master br-lan state LOWERLAYERDOWN qlen 1000
link/ether 00:51:82:11:22:01 brd ff:ff:ff:ff:ff:ff
9: br-lan: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN qlen 1000
link/ether 00:51:82:11:22:01 brd ff:ff:ff:ff:ff:ff
inet 192.168.1.1/24 brd 192.168.1.255 scope global br-lan
valid_lft forever preferred_lft forever
inet6 fd24:e7dc:ef0c::1/60 scope global tentative noprefixroute
valid_lft forever preferred_lft forever
10: br-wan: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP qlen 1000
link/ether 00:51:82:11:22:00 brd ff:ff:ff:ff:ff:ff
inet 10.4.2.110/24 brd 10.4.2.255 scope global br-wan
valid_lft forever preferred_lft forever
inet6 2a01:e0a:8ab:34b0:251:82ff:fe11:2200/64 scope global dynamic noprefixroute
valid_lft 86280sec preferred_lft 86280sec
inet6 fe80::251:82ff:fe11:2200/64 scope link
valid_lft forever preferred_lft forever
root@OpenWrt:/#
|
